450型过滤筛分机产品可供国防工业、轻工业、农业、冶金、水泥、地质、化工、医药、铸造、陶瓷、金刚石、煤炭、石油、染料、非金属等实验室及科研部门用做固体粉末的分级筛选或液体过滤，是索取数据和科学研究的实验仪器。

      Type 450 screen filter, the product can be used in the defense industry, light industry, agriculture, geological, chemical, pharmaceutical, metallurgy, cement, casting, ceramics, diamond, coal, petroleum, dye, non-metallic laboratory and scientific research departments such as used as solid powder grading screening or liquid filtration, experimental instrument data and scientific research.

450型过滤筛分机产品概述

    过滤筛分机适用于各行业生产厂家单层筛分和过滤用，处理生产量不多或杂质少的物料。450型过滤筛分机网孔不堵塞，粉末不飞扬。可筛至400目。不锈钢（304）材质，机型小巧，重量轻，可任意移动，不占空间。450型过滤筛分机采用通用新型专用动力发生器，是为顾客便于移动作业面而设计的一种高效率、低噪音、小体积的小型振动筛分过滤机；325目过滤比重1.1的喷漆料每小时可达1200公升，30目筛分面粉每小时可处理700公斤；250目过滤内墙涂料每小时可达1.5立方。在食品、陶瓷、医药、化工、油漆、冶金等行业广泛应用；在著名快餐店及连锁配送中心、面点房的面粉、面包粉的筛分除杂、果蔬原汁、豆浆过滤都有成功应用先例。

Product overview
   Filtering screening machine is suitable for industry manufacturers with a single screening and filtering, materials processing production is not much or less impurity.450 type filter screen, mesh is not blocked, powder does not float around.Mesh up to 400 mesh.Model (304) stainless steel material, small, light weight, can move arbitrarily, does not occupy a space.450 type filter screen, the universal new special power generator, is designed for customers to facilitate mobile operation of a kind of high efficiency, low noise, small volume, small vibrating screen points filter;325 mesh filter specific gravity 1.1 paint material is up to 1200 liters per hour, 30 mesh sieve flour can handle 700 kilograms per hour;250 mesh filter interior wall coating can reach 1.5 cubic per hour.In food, ceramic, medicine, metallurgy, chemical industry, paint and other industries widely used;In fast food restaurants and famous chain distribution center, pastry flour, bread flour screening in removing impurity, fruit and vegetable juice, soymilk filter has a successful application of precedent.

450型过滤筛分机产品特征

1．筛分精度高，最细可至400目。
2．筛网架设计独特，浆液不泄漏，换网快速，不易堵网。
3．体积小、重量轻、移动方便、操作简单、维护方便。
4．低能耗高效率、自动分级、连续生产。
5．适用于任何浆液、粘液和粉状物料。

Features
1. The screening of high precision, the finest to 400 mesh.
2. Screen frame design is unique, grout leakage, not in net fast, not easy plugging.
3. Small volume, light weight, mobile convenience, simple operation, easy maintenance.
4. Low energy consumption high efficiency, automatic grading, continuous production.
5. Suitable for any size, mucus, and powder material.

450型过滤筛分机主要特点

1.杂质粗料自动排出，可以自动化作业。
2.网孔不堵塞、粉末不飞扬、可筛至400目。
3.筛分、过滤效率高，任何粒、粉、粘液皆可适用。
4.独特网架设计结构，筛网使用时间长久，换网方便。
5.效率高，设计精巧耐用，任何粉类，粘液类皆可适用。
6.不锈钢（304）材质，机型小巧、重量轻、可以任意移动，不占空间。振动性能稳定、无噪音、体积小、结构简单、操作维修方便、与原料接触部分均由不锈钢材料制造（标准筛网除外）。

Characteristic
1. Impurities coarse material discharge automatically, can be automated operations.
2. The mesh plug, powder not float in the sky, the mesh to 400 mesh.
3. The screening and high filtration efficiency, can be used on any granule, powder and mucilage.
4. The unique network frame structure design, screen mesh long using time, convenient to replace the network.
5. High efficiency, exquisite design, durable, any powder, mucus class all can apply.
6. (304) stainless steel material, model compact, light weight, can not move, does not occupy a space.Vibration performance is stable, no noise, small size, simple structure, convenient operation and maintenance, and raw material contact parts are made of stainless steel materials (except standard screen).

450型过滤筛分机技术参数表

Parameters

型号	筛面有效直径	频率	功率	电压	动数	筛分粒宽
XZS-450	Φ400MM	1460次/分	0.2KW	380V	1	0.038-3MM

    另：我公司可根据用户需要而设计制造特殊型号规格的过滤筛分机。

    Another: my company can design and manufacture according to user needs special specifications of filter sieve extension.

450型过滤筛分机适用范围

    化工行业：涂料、油墨、色浆、油漆、乳胶漆、铝粉浆。
    食品行业：淀粉、豆浆、果汁、饮料、奶制品、调味品。
    其他行业：泥浆、浆粕、废液、中西药液等。

Applications
   Chemical industry: coatings, printing ink, printing ink, paint, latex paint, aluminum slurry.
   Food industry: starch, soy milk, juice, beverage, dairy products, spices.
   Other industries: slurry, pulp, waste liquid, liquid medicine of Chinese and western, etc.

450型过滤筛分机使用条件

   1、海拔不超过1000米
   2、周围环境温度：-5―40摄氏度
   3、相对温度不超过90%（20摄氏度以下）
   4、周围介质没有导电尘埃和能腐蚀和破坏绝缘的气体。

Conditions of use
  1, no more than 1000 meters above sea level
  2, the ambient temperature: - 5 to 40 degrees Celsius
  3, the relative humidity is no more than 90% (below 20 degrees Celsius)
   4 and the surrounding medium can no conductive dust and corrosion and damage the insulation gas.

450型过滤筛分机使用与维护

   1、使用前本机需水平放置，按产品所需电压（220V/380V）接通电源配置接地保护线。
   2、筛机可根据需要调节并锁紧压筛框螺丝；挂好筛框锁扣后方可使用。
   3、每次用后要清除灰尘、注意防潮，定期向电机轴承内注入锂基润滑脂。

   注意：450型为常用型号，如需其它特殊型号，我公司也可以根据您的需要定做。

The use and maintenance
 1, before using the machine should be placed, according to the product needed for voltage (220 v / 380 v) configuration earthing protection line power supply is connected.
2, sieve machine can be adjusted according to need and press lock screen screw;Hang up screen lock the rear can use.
3, every time after use to remove dirt, and pay attention to moistureproof, infuse lithium grease to motor bearing on a regular basis.
Note: type 450 for commonly used models, if you need other special models, our company can also be customized according to your need.
